Polyester Woven Dryer Fabrics

Quantity:

According to the category, polyester dryer fabrics can be divided into one and a half layer dryer fabric, double layer dryer fabric, flat wire dryer fabric, flat double warp wire dryer fabric and special material dryer fabric.


3-shed, 4-shed one layer and a half are suitable for drying cultural paper, printing paper and packing paper etc.


Flat wire and flat double warp wire dryer fabric is suitable for the fore several heating box of the drying zone, quality papers can use the both.


Special material dryer fabric have the characteristics of high temperature resistance, abrasion resistance and aging resistance etc.

 Polyester Woven Dryer Fabrics Polyester Woven Dryer FabricsPolyester Woven Dryer Fabrics Polyester Woven Dryer Fabrics


Weaving Series&Types  Model of Fabrics  Wire diameter (mm)  Density (wire/cm)  Strength(N/cm)    Permeability (m³/㎡h)
     Warp    Weft  Warp  Weft Area of the surface
 3-shed series  22503  0.50  0.50  24  12  ≥2000  8000±500
4-shed series  20504  0.50  0.50  22  12  ≥1900  13000±500
   22504  0.50  0.50  24  12  ≥2000  12000±500
   24504  0.50  0.50  26  12  ≥2100  11000±500
Round Wire Fabric  4106  0.50  0.50  22  12.4  ≥2000  6800±500


Flat Wire Fabric
 4106-1  0.38*0.58  0.50  16.66  15  ≥2000  5954±500
   4106-2  0.38*0.58  0.40/0.60  18  14.66  ≥2000  4800±500
   SL4106  0.5*0.75  0.60/0.40  14.66  12.66  ≥2100  6000±500
   SJ1860  0.25*1.05  0.60/0.90  9  7  ≥2200  2100±500
